Bicycle lift hangers on frame, 18 places

Bicycle hanger system on a separate load-bearing frame, a solution for bike rooms where fixing hangers to walls is limited or undesirable. The frame can be placed almost anywhere in the room without touching the walls; the hangers have holders for locking the bicycles with any type of lock. Can be made for any number of places. For bicycles with mudguards only the 5.5 cm slot version is compatible.

Key specifications:
Number of places: 18
Hanger depth: 50 cm
Frame dimensions (W × D × H): 613 × 115 × 205 cm
Guide rail length: 180 cm, profile 25x25x1.5 mm
Slot width (max. tyre): variant I - tyres up to 29x2.2 in (5.5 cm), variant II - up to 29x3.15 in (8 cm); compatible with brake discs up to Ø 203 mm
Tube diameter: Ø 18 mm
Tube wall thickness: 2 mm
Load-bearing frame profile: 40x40x2 mm
Material: galvanised steel
Permissible load per hanger: 30 kg
Fixing: bolt-down (to the floor and/or wall)
