Fore directional pallet mover
Manual low-lift pallet truck for EURO pallets that can travel in two mutually perpendicular directions.
Key specifications:
Fork width / length: 160 / 1150 mm
Truck width / fork height (min./max.): 540 / 85 / 200 mm
Weight: 92 kg
Load capacity: 1500 kg
- With forks raised up to 172 mm (12 pump strokes), the truck travels lengthwise only - forward and back
- At 198 mm, sideways travel engages and lengthwise travel is disengaged via the rear wheels
- The operator turns the control shaft by 90° and locks it with a pin - the truck travels left and right
- Compact manual hydraulic unit operated by the tow bar
- Control shaft with neutral and lifting modes
- Same range of use as a standard low-lift pallet truck
- Safe use requires smooth floors without holes or obstacles
Key specifications:
Fork width / length: 160 / 1150 mm
Truck width / fork height (min./max.): 540 / 85 / 200 mm
Weight: 92 kg
Load capacity: 1500 kg
- With forks raised up to 172 mm (12 pump strokes), the truck travels lengthwise only - forward and back
- At 198 mm, sideways travel engages and lengthwise travel is disengaged via the rear wheels
- The operator turns the control shaft by 90° and locks it with a pin - the truck travels left and right
- Compact manual hydraulic unit operated by the tow bar
- Control shaft with neutral and lifting modes
- Same range of use as a standard low-lift pallet truck
- Safe use requires smooth floors without holes or obstacles
